Name: ESAB ARC 630i Welding Machine 630 Amps | Heavy-Duty MMA Welder
SKU: TS-ESAB-ARC-400i-401
Price: 45103.00 INR
Availability: InStock

ESAB ARC 630i Welding Machine 630 Amps

The ESAB ARC 630i Welding Machine is a heavy-duty IGBT-based inverter welding power source designed for demanding professional and industrial welding applications. It is designed for MMA welding, Air Carbon Arc Gouging (A-CAG) and Scratch TIG applications, providing flexibility for heavy fabrication and maintenance operations.

With an operating range of 20–630 A, the ESAB ARC 630i Welding Machine 630 Amps is designed for high-current welding requirements. ESAB documentation specifies a maximum load of 630 A at 60% duty cycle and approximately 488–490 A at 100% duty cycle, depending on the documentation version.

The ARC 630i is designed for demanding applications and is described in ESAB product literature as a heavy-duty inverter power source suitable for 24×7 usage.

Key Features of ESAB ARC 630i Welding Machine

The ESAB ARC 630i combines IGBT inverter technology with adjustable welding controls and built-in protection functions.

Key features include:

Up to 630 A welding output
20–630 A operating range
Heavy-duty IGBT inverter technology
MMA / Stick welding
Air Carbon Arc Gouging
Scratch TIG welding
Adjustable Arc Force
Adjustable Hot Start
VRD safety function
Process selection for MMA and Scratch TIG
Wide mains voltage tolerance
Protection against overcurrent and thermal overload
Protection against over-voltage and under-voltage
Suitable for long welding leads
Designed for heavy-duty industrial operation

630 Amp Heavy-Duty ARC Welding Machine

The ESAB ARC 630i 630 Amp welding machine is designed for high-current MMA welding applications.

Its 20–630 A output range provides flexibility for different welding requirements. The machine is rated for 630 A at 60% duty cycle, while published ESAB documentation specifies approximately 488–490 A at 100% duty cycle.

This makes the ARC 630i suitable for applications requiring substantial welding current and extended operating capability.

When selecting welding parameters, operators should consider the electrode type, material thickness, welding position and applicable welding procedure.

IGBT Inverter Technology

The ESAB ARC 630i Welding Machine uses IGBT-based inverter technology.

The inverter design provides a high-current welding power source in a package intended for industrial applications. ESAB documentation describes the ARC 630i as a heavy-duty IGBT inverter power source for MMA welding, Air Carbon Arc Gouging and Scratch TIG.

Adjustable Arc Force and Hot Start

The ARC 630i provides adjustable Arc Force and Hot Start controls in MMA mode.

Arc Force allows the operator to adjust arc characteristics according to the welding application and electrode requirements.

Hot Start assists with arc initiation and can help achieve easier arc striking during MMA welding.

These settings should be adjusted according to the electrode manufacturer’s recommendations and the welding procedure being used.

VRD Safety Function

The ESAB ARC 630i incorporates a Voltage Reduction Device (VRD).

Published technical documentation specifies an open-circuit voltage of approximately 85 V without VRD and a reduced voltage of less than 16–20 V when VRD is activated, depending on the documentation version.

VRD is intended to reduce open-circuit voltage when the welding machine is not actively welding. Operators should always follow the manufacturer’s safety instructions and applicable workplace electrical safety requirements.

MMA, Air Carbon Arc Gouging and Scratch TIG

The ESAB ARC 630i supports multiple welding-related processes.

MMA / Stick Welding

The primary application is MMA/Stick welding. The machine is designed to provide stable performance with long welding leads and commonly used electrodes such as E6013 and E7018.

Air Carbon Arc Gouging

The ARC 630i can also be used for Air Carbon Arc Gouging (A-CAG) applications, making it suitable for heavy fabrication, repair and industrial maintenance requirements.

Scratch TIG

The machine supports Scratch TIG, providing an additional welding process for applications where TIG welding capability is required.

Long-Lead Welding Capability

The ESAB ARC 630i is designed to provide stable MMA welding performance with long welding leads.

This can be particularly useful for construction sites, fabrication facilities and industrial projects where the welding power source may need to be positioned away from the actual welding location.

Industrial Applications

The ESAB ARC 630i Welding Machine 630 Amps is suitable for demanding applications including:

Heavy fabrication
Construction projects
Erection projects
Cement plants
Process plants
Industrial maintenance
Repair and maintenance
Structural fabrication
General industrial welding
Air Carbon Arc Gouging

Published ESAB product literature specifically identifies heavy fabrication, construction and erection projects, cement plants, process plants, and repair and maintenance as application areas.

Built-In Protection

The ARC 630i includes protection functions designed for industrial operation, including protection against:

Overcurrent
Thermal overload
Over-voltage
Under-voltage
Mains voltage fluctuations

These features are intended to help protect the equipment during demanding operating conditions.

ESAB ARC 630i Specifications

Specification	Details
Brand	ESAB
Model	ARC 630i
Product Type	Inverter ARC Welding Machine
Technology	IGBT Inverter
Welding Process	MMA, Air Carbon Arc Gouging, Scratch TIG
Current Range	20–630 A
Maximum Output	630 A
Duty Cycle	630 A @ 60%
100% Duty Cycle	Approx. 488–490 A
Input Voltage	400 V, 3 Phase
Input Voltage Tolerance	-15% / +20%
Frequency	50/60 Hz
Open Circuit Voltage	85 V
VRD Voltage	<16–20 V depending on specification version
Power Factor	Approx. 0.89–0.93 depending on specification version
Efficiency	Up to 85%
Dimensions	650 × 355 × 624 mm
Weight	59 kg
Operating Temperature	-10°C to +40°C
Insulation Class	F
Application Class	S
Standards	IEC/EN 60974-1, IEC/EN 60974-10
Product Number	4610643000

The specifications above are based on ESAB ARC 630i technical documentation. Because different ESAB documentation versions list some electrical figures slightly differently, verify the exact nameplate/datasheet for the particular unit before treating those figures as contractual specifications.
